GOBIUS C NMEA2000 LIQUID METER
395,29 €
Gobius C liquid meter for NMEA 2000, plug and play installation. Measures all types of liquids, such as gasoline, diesel and oil. No need to disassemble the tank; measurement is done from the top, eliminating the risk of leakage. The package includes everything you need: sensor, NMEA 2000 cable, 3M cleaning cloth and extra 3M sensor tape. Voltage 12 volts. Installation is as easy as with other Gobius products, but the sensor is attached to the top of the tank. Maximum tank depth is 2 meters. Can be connected directly to NMEA 2000 networks. Bluetooth connection for installation and tank level monitoring.
GENERAL INFORMATION
• Suitable for all types of liquids
• Easy plug and play installation
• Automatic settings
• Built-in tank volume meter
• Built-in wave motion minimization function
• No need to remove the tank
• Reading through plastic tanks
• No tank wall thickness limit (plastic)
• Fits standard holes in metal tanks (1.25″ SAE 5).
• No need to clean the inside tank
• Maintenance-free
MEASUREMENT FUNCTIONS
• Measuring range, 20-2000 mm
• Tank depth: 2 meters (78 inches)
• Tank depth: 0.2 meters (7.8 inches).
• Measurement interval, 1 second
• Resolution: 1 mm
• Accuracy: +/- 2-3 mm
SPECIFICATIONS
• Input voltage, 9-12 V DC
• NMEA 2000 connector
• Sensor LED
• Current consumption, 10 mA
• Built-in Bluetooth, version 5.0
• Built-in temperature sensor
• Built-in accelerometer
• Built-in micro radar sensor
• Maximum voltage: 30 V
• Maximum current: 500 mA
• Bluetooth on/off
SENSOR DATA
Dimensions: height 65 mm, width 95 mm
Sensor height including metal container adapter: 75 mm
Cable length: 1 m
Sensor material: ABS
Color: black
Bluetooth: version 5.0
Waterproof: IP66
SOFTWARE
• App For iOS and Android phones
• Installation / replacement / removal
• Correct level calculation, including percentages and liters
• Bluetooth, version 5.0
• Bluetooth on/off after 10 seconds.
• Level display from phone
• Built-in test functions
• Built-in support function
| Technical name | 970534 |
|---|
