TECHNICAL DATA:
Switch type: 1-pole ON-OFF
Color: Red
Switch positions: 2
Battery connection: No
Charger field disconnection: No
Maximum voltage: 48 VDC
Terminal tightening torque: 13.56 Nm (120 in-lb)
Continuous current rating: 300 A
Instantaneous current rating: 500 A (5 min)
Starting current rating 30 s: 900 A
Battery inputs: 1 pc
Cable clearance 4/0 AWG -for cables: 28.45 mm (1.12′)
Minimum cable size: 120mm² (4/0 AWG)
Mounting holes: compatible with #10 screws
Connector size: M10 (3/8′ – 16)
Weight: 0.28 kg (0.62 lbs)
| Svars | 0,281 kg |
|---|---|
| Technical name | 6005-BSS |
